| Equipment Technical Specifications | |||||
| Specifications | Unit | 855 | 1160 | 1270 | 1370 |
| Workbench Dimensions | mm | 550x1000 | 1200*600 | 700x1200 | 1400x700 |
| X/Y/Z Shaft stroke | mm | 820*550*600 | 1100*600*600 | 1200/700/700 | 1300/700/700 |
| Distance from spindle face to worktable | mm | 130-730 | 160-740 | 120-720 | 80-780 |
| Distance from spindle center to column | mm | 590 | 650 | 672 | 785 |
| Maximum Workbench Load Capacity | Kg | 600 | 800 | 1000 | 1100 |
| T-slot workbench | mm | 5-18-100 | 5-18-100 | 5-18-100 | 5-18-122 |
| X/Y/Z-axis rapid traverse speed | m/min | 36/36/36 | 36*36*36 | 24/24/24 | 24/24/24 |
| Feed rate | m/min | 1-10000 | 1-10000 | 1-10000 | 1-10000 |
| Positioning accuracy | mm | 0.005 | 0.008 | 0.008 | 0.008 |
| Repeatability | mm | 0.005 | 0.006 | 0.008 | 0.008 |
| Maximum spindle speed | rpm | 12000 | 8000 | 8000 | 8000 |
| Transmission method | - | belt | belt | belt | belt |
| Spindle end taper | mm | BT40-155 | BT40-150 | BT40-150 | BT40-150 |
| Disc-Type Manipulator Tool Magazine | pcs | 24T | 24T | 24T | 24T |
| Controller System | / | Standard system configuration | Standard system configuration | Standard system configuration | Standard system configuration |
| Spindle Motor Power | Kw | 11 | 11 | 15 | 15 |
| Machine tool weight | Kg | 6000 | 7000 | 8000 | 8900 |
| Dimensions: Length × Width × Height | mm | 3000x2360x2400 | 3100*2380*2780 | 3340x2800x2700 | 3400x2600x2950 |
